Loft ladder clickFIX® comfort

The most comfortable loft ladder from DOLLE

Deep comfort levels
Telescopic handrail
Easy operation
Easy installation by patented articulated lever
DOLLE clickFIX® comfort scores with safety TOP thermal insulation and easy installation - telescopic handrail allows safe inspection. The ladder easy to operate thanks to spring mechanism. Built into plasterboard ceilings or finish with architraves.
Read more

Configure your product

Accessories 3 products

Products with the pencil icon require your customization after being added them to the cart.
Product description

We offer two installation solutions, built into plasterboard ceilings or finish with our architraves.

Our new DOLLE clickFIX®️ comfort loft ladder has two installation solutions where you can install into plasterboard so its flush with ceiling. Thanks to the newly developed loft ladder profile we have a durable fully integrated ceiling solution where the plasterboard is placed directlyagainst the loft ladder profile and only the trapdoor is visible at the entrance to the loft space. In the second option is you can install the traditional way using our new architraves. Either way you can visually conceal the installation joint for a seamless finish and both options are included with the loft ladder.


Comfortable treads, telescopic handrail and spring mechanism

For greater comfort and safety, the steps of the DOLLE clickFIX® comfort have been designed to be particularly deep. They are 13 cm deep and thus offer a very secure surface. The telescopic handrail allows secure grip when going up and down. On request, a second handrail can be ordered as an accessory. The DOLLE clickFIX® comfort can be operated easy and comfortably. A spring mechanism makes folding and unfolding literally feather-light.


Improved installation

The DOLLE clickFIX® comfort has a 3-section steel ladder with 11 steps for a floor to ceiling height of maximum 264 cm. The 130x70cm and 140x70cm models can be extended with an extra tread for a maximum floor to ceiling height of 278 cm. The feet of the ladder are telescopically adjustable. This allows the ladder to be easily and precisely adjusted to the ceiling height.

The new patented articulated lever is another improvement. It allows mounting without tools and convinces by an improved adjustability between lever and pivot plate. The lever is merely plugged onto the pivot plate, turned around and cannot be loosen again by itself. TIP: The lever should be oiled once a year for a long-term function. The 24 cm high casing offers better possibilities for installation in more insulated ceilings. For example, it can also be installed in lowered ceilings.

The DOLLE clickFIX® comfort can easily be assembled by one person thanks to its low weight and patented assembly technology with Click modules: align the casing, screw it on, hook in the trapdoor and ladder section and adjust to the room height, done.


Operation pole is included in this loft ladder.


Energy efficient

The patented DOLLE clickFIX® range is optimally insulated and easy to install for the transition from the warm living room to the mostly cooler loft. It prevents the loss of energy due to the air tightness which is achieved through the draught excluder. The circumferential double seals and corner seals significantly reduce the risk of condensation forming and effectively protect against possible mould growth. DOLLE clickFIX® comfort has a component-tested U-value of 0.49 W / m² · K tested by ift Rosenheim.


Control air leakage in your home

Vapour barrier with TwinActive-foil seals your product for optimal heat-insulation. Easy to attach.


Optional accessories:

Plastic feet, architraves and handrails are not included as standard.

Technical data
1
Opening size (length)
Please select a variant
2
Opening size (width)
Please select a variant
3
Floor-to-ceiling height
Please select a variant
4
Total going
Please select a variant
Product number Please select a variant
EAN Please select a variant
Opening size (length) Please select a variant
Opening size (width) Please select a variant
Floor-to-ceiling height Please select a variant
Total going Please select a variant
Swing clearance Please select a variant
Horizontal clearance Please select a variant
U-value (W/m²* K) 0.4900
Attic ladder type Please select a variant
Usage Manual
Sections Please select a variant
Ladder material Steel
Trapdoor material Sandwich construction
Trapdoor thickness 76 mm
Insulation 70 mm
Casing material Laminated pine, white
Casing thickness 18 mm
Outside casing (length) Please select a variant
Outside casing (width) Please select a variant
Casing (height) Please select a variant
Number of treads Please select a variant
Tread rise 235 mm
Tread material Steel
Tread thickness 32 mm
Tread width Please select a variant
Tread depth 130 mm
Maximum height with additional treads Please select a variant
String material Steel
String thickness 20 mm
String depth 40 mm
Maximum load 150 kg
Product weight Please select a variant
Tested U-value - tested as building component by testinstitute: IFT Rosenheim, Airtight EN 12207 class 4, EN 1026:2016, Manufactured according to EN 14975
