Loft ladder clickFIX® 56S

Loft ladder in high quality and easy installation from DOLLE

Easy 1-person installation process
Lightweight and easy to operate, handrail included
10-year guarantee
Maximum floor to ceiling height 274 cm
Loft ladder clickFIX® 56S is part of the unique loft ladder line from DOLLE. The entire patented clickFIX® range is known by low u-value and the quick and easy installation. The insulation and the construction of the trapdoor reduces heat loss.
Read more

Configure your product

Accessories 5 products

Products with the pencil icon require your customization after being added them to the cart.
Product description

Easy to install for trade professionals and DIY’ers

Thanks to its low weight and patented assembly technology with click modules, clickFIX® can also be easily installed by one person. It's simple, align the 190 mm high casing, screw in place, click on the trapdoor and ladder section and adjust to the room height, job done.To ensure a perfectly airtight installation.

High quality loft ladders form the transition from the living area to the loft space. In addition to a simple and safe installation process the clickFIX® also prevents the loss of energy preventing the escape of warm air from the living area. The patented loft ladder DOLLE clickFIX® 56S meets all requirements in one system: Thanks to its modular construction and easy installation along with excellent insulation properties the loft ladder has a component U-value of 0.64 W / m²K.


Low u-value

Also on the clickFIX® 56S the u-value is very low compared to other loft ladders on the market. Especially because all our clickFIX® loft ladders are tested as building component, like doors and windows.


Control air leakage in your home

Vapour barrier with TwinActive-foil seals your product for optimal heat-insulation. Easy to attach.


Optional accessories:

Plastic feet, architraves and handrails are not included as standard.

Technical data
1
Opening size (length)
Please select a variant
2
Opening size (width)
Please select a variant
3
Floor-to-ceiling height
Please select a variant
4
Total going
Please select a variant
Product number Please select a variant
Finish White
U-value (W/m²* K) 0.6400
Ladder material Wood
Casing material Spruce
Trapdoor material Sandwich construction
Casing (height) Please select a variant
Maximum floor-to-ceiling height Please select a variant
Maximum load 150 kg
Swing clearance Please select a variant
Tested U-value - tested as building component by testinstitute: IFT Rosenheim, Airtight EN 12207 class 4, EN 1026:2016, Manufactured according to EN 14975
Attic ladder type Folding ladder
Usage Manual
Tread rise 235 mm
Tread thickness 17.5 mm
Tread width Please select a variant
Tread depth 69 mm
Trapdoor thickness 56 mm
Going Please select a variant
Number of risers Please select a variant
String depth 69 mm
String thickness 21 mm
String material Pine
Fire resistance Please select a variant
Fire resistance class None
