Loft ladder clickFIX® 56 MINI PRO+
Very space saving loft ladder with top insulation
Product description
The perfect loft ladder for narrow space
A complete and unique loft ladder from DOLLE. Its design is perfect for narrow hallways, where it is easily mounted between the beams. The loft ladder is equipped with a strong ladder with a 6.9 cm non-slip beech treads, which provides a good comfortable tread. The 4-part ladder has 12 steps and a ladder width of 35.8 cm. The spruce casing is white-primed and thus ensures a nice finish. The total strength of the loft ladder has been tested according to EN 14975 which has a max. user weight of 150 kg, but tests the stairs up to 265 kg.
ENERGY SAVING
A DOLLE clickFIX® 56 MINI PRO+ loft ladder meets the high energy requirements of the housing market today. DOLLE clickFIX® 56 MINI PRO+ is insulated with 50 mm expanded polystyrene (EPS). U-value: 0.64 W / m2 * K. The low u-value is particularly remarkable, as all the products have been tested as a building component similar to doors and windows. Tested at the IFT Rosenheim Institute for both U-value and air tightness. In the casing there are two sealing strips and a corner strip which ensures an extra airtight. The construction of the trapdoor prevents heat loss and cold bridges from the loft ladder. It can be easily mounted by just one person due to the simple click mounting.
Control air leakage in your home
Vapour barrier with TwinActive-foil seals your product for optimal heat-insulation. Easy to attach.
Optional accessories:
Plastic feet, architraves and handrails are not included as standard.
Technical data
|
1
|
95 cm |
|---|---|
|
2
|
70 cm |
|
3
|
273 cm |
|
4
|
118 cm |
| Product number | 1039771 |
| Finish | White |
| Opening size (length) | 95 cm |
| Opening size (width) | 70 cm |
| Floor-to-ceiling height | 273 cm |
| Total going | 118 cm |
| Swing clearance | 117 cm |
| U-value (W/m²* K) | 0.6400 |
| Attic ladder type | Folding ladder |
| Usage | Manual |
| Sections | 4-section |
| Ladder material | Wood |
| Trapdoor material | Sandwich construction |
| Trapdoor thickness | 56 mm |
| Insulation | 50 mm |
| Casing material | Spruce |
| Casing thickness | 18 mm |
| Outside casing (length) | 92.5 cm |
| Outside casing (width) | 67.6 cm |
| Casing (height) | 14 cm |
| Number of treads | 12 |
| Tread material | Solid beech |
| Tread width | 358 mm |
| Tread depth | 69 mm |
| String material | Pine |
| String thickness | 21 mm |
| String depth | 69 mm |
| Maximum load | 150 kg |
| Tested | U-value - tested as building component by testinstitute: IFT Rosenheim, Airtight EN 12207 class 4, EN 1026:2016, Manufactured according to EN 14975 |
