Loft ladder clickFIX® 36G

Loft ladder with market leading insulation thanks to patented technology

Value for money
Energy efficient
Manufactured according to EN 14975
Easy assembling
clickFIX® 36 Gold is part of the popular clickFIX® range, its patented innovative technology makes it possible to assemble both quickly and by one person. The clickFIX® 36G is designed with 30 mm of insulation in the trapdoor.
Read more

Configure your product

Accessories 3 products

Product description

Achieve high Energy efficiency with clickFIX®

clickFIX® loft ladders from DOLLE is a high-class product, where quality is a main focus in the product. DOLLE is the market leader of loft ladders and ensure the lowest U-value on the market and easy installation due to the clickFIX® technology. The clickFIX® 36Gold is designed with 30 mm of insulation in the trapdoor, a great support against cold bridges/draughts.


The composition of the loft ladder

The loft ladder basically contains three main parts. First there is the casing, then the trapdoor and last but not least the ladder. The part separating the loft ladders from each other is the trapdoor. In contrast to a traditional loft ladder where the trapdoor is made of both wood and expanded polystyrene, the trapdoor in a clickFIX® product is only made of expanded polystyrene and a white HDF plate on both sides. The ladder is made of spruce which provides a solid and very strong ladder in a great quality, so the ladder can last for many years even when using it on a daily basis.

Optional accessories:

Plastic feet, architraves and handrails are not included as standard.


Control air leakage in your home

Vapour barrier with TwinActive-foil seals your product for optimal heat-insulation. Easy to attach.


Optional accessories:

Plastic feet, architraves and handrails are not included as standard.

Technical data
1
Opening size (length)
Please select a variant
2
Opening size (width)
Please select a variant
3
Floor-to-ceiling height
Please select a variant
4
Total going
Please select a variant
Product number Please select a variant
Finish White
U-value (W/m²* K) 0.9900
Ladder material Wood
Casing material Spruce
Trapdoor material Sandwich construction
Casing (height) Please select a variant
Maximum floor-to-ceiling height Please select a variant
Maximum load 150 kg
Swing clearance Please select a variant
Tested U-value - tested as building component by testinstitute: IFT Rosenheim, Airtight EN 12207 class 4, EN 1026:2016, FSC® certified wood, Manufactured according to EN 14975
Attic ladder type Please select a variant
Usage Manual
Tread rise 235 mm
Tread thickness 28 mm
Tread width Please select a variant
Tread depth 82 mm
Trapdoor thickness 36 mm
Going Please select a variant
Number of risers Please select a variant
String depth 84 mm
String thickness 21 mm
String material Spruce
Fire resistance Please select a variant
Fire resistance class Please select a variant
