Fire-resistant loft ladder REI 45 comfort
Fire-resistant loft ladder with even better comfort thanks to the steel ladder.
Product description
Fire-resistant loft ladder with steel ladder from DOLLE
DOLLE REI 45 comfort is our new fire-resistant loft ladder from DOLLE - a comfortable and smart steel ladder. REI is the new European classification that replaces the old fire-resistant classifications.
The new European fire requirements are described from the loft ladders:
1) R (resistance) carrying capacity during fire.
2) E (integrity) ability to keep flames and gases out.
3) I (insulation) ability to keep warm out.
After the classification, the time period for which the loft ladder can withstand fire is indicated by the DOLLE REI 45 so that the fire-resistant loft ladders are fireproof for 45 minutes.
The trapdoor is insulated with a 50 mm rockwool plate, which is made of non-combustible, moisture and water-repellent Rockwool stone wool. The trapdoor has a quality finish in white HDF plate with hidden hinges with a high quality lock.
Fire-resistant loft ladder with comfort and steel ladder
Focusing on comfort, DOLLE has also a fire-resistant loft ladder with an anthracite steel ladder. The ladder comes with a high quality spring system making the loft ladder extra easy to handle! Just like a feather. To provide extra comfort and safety, the loft ladder is equipped with 13 cm deep anti-slip treads and with its long telescope handrail, it provides security accessing the loft space. It also has an option to fit an additional handrail to the ladder for support on both sides! The DOLLE REI comfort meets the demand for more safety, super easy handling and comfort.
All loft ladders from DOLLE are tested in accordance with EN 14975.
Technical data
|
1
|
120 cm |
|---|---|
|
2
|
70 cm |
|
3
|
271 cm |
|
4
|
120 cm |
| Product number | 1010775 |
| EAN | 5708580107755 |
| Opening size (length) | 120 cm |
| Opening size (width) | 70 cm |
| Floor-to-ceiling height | 271 cm |
| Total going | 120 cm |
| Swing clearance | 153 cm |
| U-value (W/m²* K) | 0.9600 |
| Attic ladder type | Folding ladder |
| Usage | Manual |
| Sections | 3-section |
| Ladder material | Steel |
| Trapdoor material | Sandwich construction |
| Trapdoor thickness | 56 mm |
| Insulation | 50 mm |
| Casing material | Blockboard |
| Casing thickness | 18 mm |
| Outside casing (length) | 117.5 cm |
| Outside casing (width) | 67.6 cm |
| Casing (height) | 19 cm |
| Number of treads | 11 |
| Tread material | Steel |
| Tread thickness | 30 mm |
| Tread depth | 130 mm |
| String material | Steel |
| String thickness | 20 mm |
| String depth | 40 mm |
| Maximum load | 150 kg |
| Tested | U-value - tested as building component by testinstitute: IFT Rosenheim |
